500W full-protection fiber laser cutting machine HS-M3015A

Name: 500W fullprotection fiber laser cutting machine HSM3015A
Brand: HSG laser
Price: 1 USD

Place of Origin : Foshan

Brand Name : HSG laser

Model Number : HS-M3015A

Certification : 1.CE certificate. 2.ISO certificate. 3.FDA certificate.

Packaging Details : Seaworthy wooden cases with packaging film and protecting foam inside.

Delivery Time : 5 to 30 days depending on different models and quantity.

Payment Terms : 30% in advance as deposit, balance after quality check and before shipment.

Supply Ability : more than 2000 sets/year

MOQ : 1 set

Contact Now

Product description:

Technical parameter

Working table（mm）	1500*3000	Laser power(W)	500/1000
Weight（kg）	5000	Max. running speed	40m/min
Machine body size（mm）	5100×2980×2150	Max.Acceleration Speed	0.3G

Fiber laser cutting bed HS-M3015A features:

(1. Fully closed protective cover and integrated design, coving space of only 19m2, left and right collecting drawers design highly saving space.

2. Equipped with US IPG fiber laser source, Japan Sanyo servo motor and Taiwan Hiwai ball screw and guide rail.

3.Adopt Japanese SMC intellignet gas group design, with low-pressure drilling, automatic gas swiching and pressure detecting functions.

4. Specially used for cutting0.5-6mmcarbon steel,0.5-3mmstainless steel, galvanized steel, electrolytic zinc-coated steel sheet, silicon steel and other kinds of thin metal sheets(The thickness and materials depend on different fiber laser source).

5. Technical parameters of Fiber laser cutting bed HS-M3015A:

Transmitting structure	Precise ball screw transmitting
Max running speed	40m/min
X/Y location precision	0.05mm/m
Working Power Supply	380V 50Hz
X/Y repeated location precision	±0.05mm
Laser source power	500/1000W
Running Temperature	0°C-40°C
Max Acceleration	0.3G
Formats	BMP、DXF、PLT、GPEG、DST、CDR
Applied Materials	Thin mild steel, stainless steel and other kinds of metallic sheets(non-ferrous metal not suggested)

Sample:

500W full-protection fiber laser cutting machine HS-M3015A

Packing:

500W full-protection fiber laser cutting machine HS-M3015A

About HSG laser:

HSG laser is the best laser cutting bed manufacture in China and HSG laser also is the number hot-sale laser cutting bed producer in China.

HSG laser advantages:

HSG laser is the only one manufacturer carrying out 100% testing in the whole Chinese laser industry.
HSG laser is the only one Chinese supplier provides 3 years guarantee for the machine in China.

Company certificates:

CE certificate.
ISO certificate.
FDA certificate
